Universal, Secure
X-Station is a formidable device that combines a vast array of
components into a slim form factor. X-Station’s 3.5” touchscreen
LCD provides the perfect interface to an intuitive UI and its camera,
speaker and microphone allows for advanced features such as
Face Detection and Videophone capabilities. It is a versatile product
that can be used in a variety of applications.

X-Station-Pic



Specifications

CapacityMax User200,000X-Station-Dimension

Max Template-

Max Log1000,000 (Text) | 5,000 (Image)

InterfaceComm.TCP/IP, RS485

Wiegand1ch Host and Slave

Input / Output2 TTL Inputs | 1 Relay

H/WCPU667MHz RISC

Memory128MB RAM + 1GB Flash

LCD3.5" Color touch

Operating Temp.-20° to 50°C

Power12VDC

Dimensions79 x 135 x 21 mm (W x H x D)
