ASK [EM] Format
Proximity Card & Key Tag
KEY Features
• ISO Credit Card Size and Thickness (IPC80)
• ASK [EM] Format
• 125KHz / Passive Type
• Combination available with Magnetic Stripe (IPC80)
• Printing Company Logo with Graphic (IPC80 – Front & Rear)
• Key Tag (IPK50)
• Options: Magnetic Stripe (High Coercivity – IPC80)
Specifications
Model | IPC80 | IPC170 | |
---|---|---|---|
Frequency | 125KHz | ||
Read Range | IP10/20/IPK101 | Up to 4 inch (10cm) | |
IP-FINGER007 | Up to 4 inch (10cm) | ||
RF10/20/TINYRFK101 | Up to 4 inch (10cm) | ||
IP-FINGER006 | Up to 4 inch (10cm) | ||
IP-FGR006 | Up to 4 inch (10cm) | ||
IP505R | Up to 4 inch (10cm) | ||
IP-RFL200 | Up to 4 inch (10cm) | ||
IP100R | Up to 4 inch (10cm) | ||
Encoding | Compatible with ASK[EM] type of 125KHz | ||
Graphics | Customized color available | ||
Operating Temperature | -30°to +65°C (-22°to +149F) | ||
Operating Humidity | 10% to 90% relative humidity non-condensing | ||
Color | Card Holder | Transparency | |
Card | White | ||
Weight | 5.5g (0.01lbs) | 9g (0.02lbs) | |
Material | Card Holder | Polycarbonate | |
Card | PVC | ABS |
